Medical Microscope

Medical Microscope

Designed for routine enhanced bright field applications in the Professional Laboratory as well as in Colleges and Further Educational establishments. Standard plano concave mirror 50 mm dia. in fork for natural light, replaceable by a substage microscope lamp.

Key Features:

• Monocular body with horse shoe shaped base hinged type, versatile designed inclinable to 90deg assembled from DIE-CAST parts
• Viewing Tube Mechanical tube of length 160+1 mm
• Eyepiece KEOWA 10x (WF), H15x or H5x
• Objectives KEOWA 10x, 40x (SL) & 100x Oil Imm (SL)
• Focusing rack and pinion knob provided for sensitive focusing
• TRIPLE or QUADRUPLE revolving nosepiece with positive centering and click stop
• Condenser TWO LENS ABBE condenser NA 1.25 with continuously variable iris diaphragm and swing-out filter holder
• Illumination STANDARD plano concave mirror 50 mm dia. in fork for natural light, replaceable by a substage microscope lamp
• WESWOX Eyepiece WF 10x, H15x & Achromatic objectives 10x, 45x & KEOWA JP series Achromatic Objectives 100x
• Fixed square stage of size 120mm x 120mm fitted with Phosphorus stage clips and detachable graduated mechanical stage for X and Y movement upto 40mm to 75mm
• Knobs separate coarse and fine motion knobs with very precise & accurate graduated fine motion reading to 0.002mm, for fine adjustment and a stopper to prevent damage to glass microslides and objective lenses.
